Spiral tooth design, the base material has both rigidity and toughness, and the parts mesh well; the gear is made of low-carbon alloy steel, and the surface hardness of the gear is carburized and quenched to HRC62 to obtain the best wear resistance and impact resistance toughness.
Product Parameters
Wide versatility (power): 6W~250W
High load and impact resistance
Easy installation, low noise
Reduction ratio(High Torque): 3~2000
Applications
Micro-reducers are mainly used in conveying machinery, packaging machinery, food machinery, textile machinery, office machinery, printing machinery, electronic instruments, medical equipment, chemical instruments, public hazard prevention machinery, sports machinery, special professional machinery, wire and cables, finance and other fields. It is the most ideal supporting product for automation equipment in various industries.
| MICRO AC MOTOR | 6W | 15W | 25W | 40W/60W | 90W/120W | 140W/160W | 180W/200W | 250W |
| Reduction Ratio | 3~200 | 3~200 | 3~2000 | 3~2000 | 3~2000 | 3~200 | 3~200 | 3~200 |
| 50HZ Rated torque | 0.13~3N.M | 0.30~5N.M | 0.50~8N.M | 0.77~10N.M(40W)
1.19~20N.M(60W) |
1.79~20N.M(90W)
2.25~20N.M(120W) |
2.62~44N.M(140W)
2.76~44N.M(160W) |
3.1~44N.M(180W)
3.44~44N.M(200W) |
4.26~44N.M |
| 60HZ Rated Torque | 0.11~3N.M | 0.25~5N.M | 0.41~8N.M | 0.64~10N.M(40W)
0.99~20N.M(60W) |
1.49~20N.M(90W)
1.87~20N.M(120W) |
2.19~44n.m(140W)
2.48~44N.M(160W) |
2.76~44N.M(180W)
2.87~44N.M(200W) |
3.83~44N.M |
| 50HZ Max output speed | 7-433r/min | 7-433r/min | 0.7-433r/min | 0.7-433r/min | 0.7-433r/min | 7-433r/min | 7-433r/min | 7-433r/min |
| 60HZ Max output speed | 8-533r/min | 8-533r/min | 0.8-533r/min | 0.8-533r/min | 0.8-533r/min | 8-533r/min | 8-533r/min | 8-533r/min |
